Bacteriological Incubator

Product Description

We have always strive to offer our client an excellent range of Bacteriological Incubator that is widely used for day to day bacteriological and culture tests performed in various laboratory applications. The offered incubator is manufactured from optimum quality of components as per defined market norms. Moreover, this incubator is tested on various quality parameters at our sound manufacturing division to ensure its flawlessness at clients end. Apart from this, our clients can avail this Bacteriological Incubator from us in at market leading price.

Features:

Further Details:

Temperature Range : 10 C to 60C

Accuracy :  0.5C

Construction

This unit has double walled chamber, with glass wool/PUF insulation. This unit has full-length inner glass door and outside metal door with magnetic gasket and lock. Forced air circulation for uniform temperature. Intellligent Control System

Temperature Controller with Ethernet Communication

Heating System

Long lasting stainless steel tubular heaters with s.s. fins.

Sensor

Temperature transmitter 4-20mA used for measurement. Temperature in degree Celsius with 0.1C resolution.

Cooling System

Hermitically sealed compressor coupled with evaporation coil and condenser, safe guarded by time delay circuit. CFC free refrigerant

Alarms

Audio and visual alarms are generated for temperature variation

Safety

The unit is provided with safety devices for temperature over shoot in case of malfunction.

The unit works on 230 Volts AC and 50Hz mains supply.

Selection Guide

Eqp - Equipment Shp Shipping

Optional

Common Software: Chambers are connected on TCP/IP (Ethernet) with the centralized work station and transferring data in database. This centralized workstation provides the tool for viewing, trending and alarm management of chambers. It has date and time stamp audit trails and complies to US FDA 21 CFR Part 11.

Temperature Scanner: 4 point scanner for temperature having 4 temperature probes provided with alarms to monitor various parts of equipment.

Door Access System: The door access system restricts access to the chamber to authorized persons only. In this system a physical lock is provided additional to this password access control is provided. Maximum six users can access the chamber.

Remote Alarm System: Alarm for Temperature & Humidity deviations. Indicator LED to identify equipment deviation. Alarm hooter test push button.

Mobile Alert System Suitable for Newtronic Equipments whenever the alarm is generated by the system the user has to acknowledge the alarm with in predetermined time. If the user fails to acknowledge the alarm will send as a sms to 6 predefined numbers.
